Electronics
MOTOR
BLACK 48V BRUSHLESS GEARED REAR HUB MOTOR; 500 WATT NOMINAL POWER RATING; 45NM TORQUE; QUICK DISCONNECT CABLE W/ WATERPROOF CONNECTION
BATTERY
48V 10AH W/ LG 21700 LI-ION CELLS OR 48V 14AH W/ LG 18650 LI-ION CELLS
CHARGER
PEDEGO FANLESS 48V 2.0A SMART CHARGER STANDARD; 48V 4.0A SUPERCHARGER AVAILABLE AFTERMARKET
CONTROLLER
48 VOLT 18 AMP SINE WAVE CONTROLLER W/ CUSTOM PEDALSENSE® SOFTWARE AND WATERPROOF CONNECTIONS
THROTTLE
CUSTOM PEDEGO TWIST AND GO THROTTLE W/ THREADED WATERPROOF CONNECTION
PEDALSENSE®
FREE RIDE MODE (NO POWER), FIVE LEVELS OF PEDAL ASSIST W/ THROTTLE OVERRIDE, AND THROTTLE ONLY MODE
DISPLAY
2.5” BACKLIT LCD SCREEN; 3 BUTTONS TO CONTROL ELECTRONICS, TOGGLE INFO DISPLAYED, AND CUSTOMIZE SETTINGS; USB CHARGING PORT; WATERPROOF THREADED CONNECTION; CUSTOM PEDALSENSE® SOFTWARE
TOP SPEED
2O MPH W/ MOTOR ASSISTANCE ONLY
----------------
Drivetrain
DERAILLEUR
MICROSHIFT RD-M26S-7 7-SPEED; RESIN BODY W/ ENGINEERING COMPOSITE PULLEYS; FRAME MOUNTED DERAILLEUR PROTECTOR
CASSETTE
SHIMANO HYPERGLIDE HG20 7 SPEED 12-32T; SMOOTH, LIGHT AND RELIABLE SHIFTING PERFORMANCE
SHIFTER
MICROSHIFT TS71-7R RIGHT HAND THUMB-TAP SHIFTER W/ OPTICAL GEAR DISPLAY
BOTTOM BRACKET
120MM X 179.5MM SQUARE TAPER SPINDLE W/ SEALED CARTRIDGE BEARINGS; STEEL CUPS AND BODY
CHAIN
KMC Z7 1/2”X3/32” 110 LINKS
CRANKSET
BLACK 3 PIECE CRANK W/ 5X130MM 48T 3/32” STEEL CHAINRING; 170MM FORGED ALUMI- NUM CRANK ARMS
PEDALS
WELLGO COMPOSITE PLATFORM PEDAL; 9/16” SPINDLE; INTEGRATED PEDAL REFLECTORS
----------------
Brakes
CALIPERS
TEKTRO MD-M280 MECHANICAL DISC BRAKES; INTUITIVE EASY TO USE ADJUSTABILITY; 5MM HEX INBOARD PAD ADJUSTMENT; INTEGRATED CABLE STOP W/ BARREL ADJUSTER
LEVERS
BLACK ERGONOMIC LEVER W/ RUBBER FINGER PADDING; INTEGRATED MOTOR CUT OFF SWITCH FOR MAXIMUM SAFETY
PADS
TEKTROA10.11 METAL CERAMIC PAD W/ STEEL BACKING PLATE; OE QUALITY FOR NO- COMPROMISE DISC BRAKE PERFORMANCE
ROTORS
TEKTRO TR 160-24 STAINLESS STEEL; 160MM DIAMETER
---------------
Components
FRAME
20” FAT TIRE 6061-T6 ALUMINUM ALLOY; FULLY-INTEGRATED DOWNTUBE BATTERY MOUNT; SEMI-INTERNAL CABLE ROUTING
FORK
20” FAT TIRE RIGID STEEL FORK; 1 1⁄8” THREADLESS STEERER TUBE; DISC BRAKE AND FENDER MOUNTS
HEADSET
ZERO STACK SEMI-INTEGRATED 1-1/8” X 1-1/2 THREADLESS; ZS44/28.6 | ZS56/30
SEATPOST
BLACK 30.4MM X 350MM ALUMINIUM ALLOY RIGID SEATPOST; SHIM INCLUDED IN KIT BOX FOR 27 2MM AFTERMARKET SEATPOST
SADDLE
MTB STYLE W/ SINGLE DENSITY LIGHTWEIGHT FOAM; CHROMOLY RAILS; CENTER CHANNEL RELIEF; 270MM L X 165MM W
RIMS
20” X 3” FAT TIRE ALUMINUM ALLOY DOUBLE WALL RIMS; FRONT 13G X 36H / REAR 12G X 36H
SPOKES
SILVER HEAVY DUTY STAINLESS STEEL SPOKES W/ BRASS NIPPLES
GRIPS
BLACK CLASSIC MUSHROOM STYLE RIBBED RUBBER GRIPS; CUSTOM PEDEGO DESIGN
HANDLEBAR
BLACK MTB RISER; ALUMINUM ALLOY; 31.8MM STEM CLAMP DIAMETER; 30MM RISE; 640MM WIDTH
STEM
BLACK ALUMINUM ALLOY; 90MM LENGTH; 31.8MM HANDLEBAR CLAMP DIAMETER; 1 1⁄8 (28.6MM) THREADLESS STEERER TUBE CLAMP DIAMETER
TIRES
KENDA BLACK WALL 20” X 4.0”; SINGLE RUBBER COMPOUND; WIRE BEAD; 30 PSI MAX; 20”X 4.0” INNER TUBE, SCHRADER VALVE
-----------------
Extras
LIGHTS
HEADLIGHT AVAILABLE AFTERMARKET
KICKSTAND
BLACK ALUMINUM ALLOY REAR KICKSTAND; ADJUSTABLE LENGTH COMPOSITE FOOT
FENDERS
FENDER SET AVAILABLE AFTERMARKET; MATTE BLACK ALUMINUM FENDERS W/ STAINLESS STEEL HARDWARE
REAR RACK
REAR RACK AVAILABLE AFTERMARKET; MATTE BLACK ALUMINUM; 25KG MAX WEIGHT CAPACITY
TOOL KIT
CUSTOM PEDEGO TOOL KIT: 6” ADJUSTABLE WRENCH (UP TO 15MM), 12/13G SPOKE WRENCH, T25 TORX WRENCH, 6MM HEX WRENCH, 5MM HEX WRENCH W/ #2 PHILLIPS SCREWDRIVER, 4MM HEX WRENCH
BELL
BLACK LEFT HAND MINI ALUMINUM BELL
--------------
Weight
BIKE (NO BATTERY)
ONE SIZE: 52.8 LB
BATTERY
48V/10AH: 6.4 LB; 48V/14AH: 7.6 LB
