GENERAL INFO
MODEL
Boomerang: Platinum Edition
WEIGHT LIMIT
250 LB
IDEAL USE
Cruising
SPEED
20 MPH or 28 MPH
RANGE
UP TO 75 MILES
PEDAL ASSIST
3 Levels
RIDER HEIGHT
5'2"+
ELECTRONICS
MOTOR
BLACK 52V BRUSHLESS GEARED REAR HUB MOTOR; 749 WATT NOMINAL POWER RATING; 60NM TORQUE; QUICK DISCONNECT CABLE WITH WATERPROOF CONNECTION.
BATTERY
52 VOLT 17.5 OR 10.5 AMP HOUR WITH PREMIUM LITHIUM ION 18650 CELLS; SMART BIKE TECHNOLOGY WITH CANBUS COMMUNICATION; AUTO SLEEP FUNCTION.
CHARGER
52V 2 AMP PEDEGO FANLESS BATTERY CHARGER WITH CHARGE INDICATOR LIGHT.
CONTROLLER
52 VOLT 22 AMP SINE WAVE CONTROLLER WITH CUSTOM PEDALSENSE® SOFTWARE AND WATERPROOF CONNECTIONS.
DRIVETRAIN
DERAILLEUR
SHIMANO DEORE M6000 10 SPEED; INTEGRATED CLUTCH FOR MAXIMUM CHAINRETENTION; RIDER TUNED FOR SHARP AND SILKY SHIFTS; MODEL NO: RD-M6000-10-SGS.
CASSETTE
SHIMANO DEORE M6000 10 SPEED HYPERGLIDE 11-36T; PRECISE AND CONSISTENTSHIFTING PERFORMANCE; MODEL NO: CS-HG50-10.
SHIFTER
SHIMANO DEORE M6000 10 SPEED; DYNA-SYS WITH OPTICAL GEAR DISPLAY; MODEL NO:SL-M6000-10-R.
BOTTOM BRACKET
68MM x 127.5MM SQUARE TAPER SPINDLE WITH SEALED CARTRIDGE BEARINGS;INTEGRATED TORQUE SENSOR.
CHAIN
10 SPEED KMC X10EPT; RUSTBUSTER TREATMENT.
CRANK
BLACK 3 PIECE CRANK WITH 5x130MM 52T 3/32” CHAINRING; 170MM FORGED ALUMINUMCRANK ARMS.
PEDALS
BLACK WELLGO ALUMINUM PLATFORM PEDAL; 9/16” SPINDLE; SEALED CARTRIDGEBEARING/ POLYMER DU BUSHING; INTEGRATED PEDAL REFLECTORS.
BRAKES
CALIPERS
STAR UNION 2 PISTON FORGED ALUMINUM HYDRAULIC DISC BRAKE; MINERAL OIL BRAKEFLUID
LEVERS
STAR UNION 3 FINGER BALL END LEVER; CAST ALUMINUM WITH MOTOR CUTOFF SWITCH FORMAXIMUM SAFETY
PADS
CERAMIC MATERIAL WITH STEEL BACKING PLATE; OFFER SAFETY TOGETHER WITHEXCELLENT PERFORMANCE IN ALL SITUATIONS.
ROTORS
STAINLESS STEEL;180MM DIAMETER; STIFF, DURABLE DESIGN WITH A STRAIGHT,PREDICTABLE BRAKING SURFACE.
COMPONENTS
FRAME
6061-T6 ALUMINUM ALLOY; INTEGRATED REINFORCED REAR RACK FOR BATTERY AND STORAGE; INTERNAL CABLE AND WIRE ROUTING
FORK
24” or 26” AIR SPRUNG SUSPENSION FORK; 80MM TRAVEL; 1 ⅛” THREADED STEERER TUBE;ADJUSTABLE COMPRESSION WITH HYDRAULIC LOCKOUT.
HEADSET
BLACK ZERO STACK SEMI-INTEGRATED 1 ⅛” THREADED; ZS44/28.6-26TPI | ZS44/30
SEATPOST
CANE CREEK THUDBUSTER ST ELASTOMER SUSPENSION SEATPOST; PARALLEL LINKAGETECHNOLOGY DELIVERS A CLEAR ADVANTAGE IN COMFORT AND CONTROL; 27.2MM x 350MMWITH 33MM OF TRAVEL.
SADDLE
EXTRA WIDE CRUISER STYLE SADDLE WITH SOFT FOAM; REAR FACING PEDEGO LOGO; 265MML x 265MM W.
RIMS
24” OR 26” ALUMINUM ALLOY DOUBLE WALL RIMS; 24.7MM INTERNAL WIDTH; PINNED JOINT;3D ANGLE DRILLED SPOKE HOLES; 12G X 36 HOLE.
SPOKES
BLACK 12 GAUGE HEAVY DUTY STAINLESS STEEL SPOKES WITH BRASS NIPPLES.
GRIPS
PEDEGO SYNTHETIC LEATHER GRIP WITH HAND STITCHING AND FOAM PADDING; COLORMATCHED BALLOON PACKAGE.
HANDLEBAR
BLACK ERGONOMIC CITY STYLE; ALUMINUM ALLOY; 25.4MM CLAMP DIAMETER; 650MMWIDTH
STEM
BLACK QUICK RELEASE ADJUSTABLE QUILL STYLE; 110MM LENGTH; 0-80 DEGREE ADJUSTABLE ANGLE; 25.4MM HANDLEBAR CLAMP DIAMETER; HEIGHT ADJUSTABLE 0-60MM; FOR 1⅛” (28.6MM) THREADED STEERER TUBE
TIRES
SCHWALBE FAT FRANK 26” x 2.35” or BIG BEN 24” x 2.15” WITH K-GUARD KEVLAR FLATPROTECTION; SLIME INNER TUBE SEALANT; SCHRADER VALVE.
EXTRAS
LIGHTS
FRONT: LED WITH ADJUSTABLE MOUNT 60 LUX;REAR: LED BUILT INTO BATTERY WITH BRAKE LIGHT AND TURN SIGNAL FUNCTIONS; BOTHPOWERED BY MAIN BATTERY AND CONTROLLED BY LCD.
KICKSTAND
BLACK ALUMINUM ALLOY CENTER KICKSTAND; ADJUSTABLE LENGTH COMPOSITE FOOT
TOOL KIT
CUSTOM PEDEGO TOOL KIT: 6” ADJUSTABLE WRENCH (UP TO 15MM), 12/13G SPOKEWRENCH, T25 TORX WRENCH, 6MM HEX WRENCH, 5MM HEX WRENCH WITH #2 PHILLIPSSCREWDRIVER, 4MM HEX WRENCH.
WEIGHT
BATTERY
52V/17.5Ah: 10.0 LB; 52V/10.5Ah: 8.8LB
BIKE (NO BATTERY)
STEP THRU 24”: 54.4 LB; STEP THRU 26”: 53.4 LB
